PROJECT DETAILS
| Product Name： | 2.4G Current Monitoring RFID Tag |
|---|---|
| Product Model： | MR3872C |
| Product Category： | RFID 2.4GHz Active Tag |
Product overview
- 1, Measure up to GB2099.1-2008 and GB1002-2008 standard three-pin plug and socket. More safe and reliable.
- 2, Power supply by AC，standby battery inside, working above 5 years.
- 3, Tamper alarm device avoid spite remove.High Precision current measurement, error less than 0.1%
- 4, Inside 2.4G RFID antenna, transmitting distance 80 meters.?2.4G Current Monitoring RFID Tag MR3872C suit for information assets management of electrical?equipments. It adopt RFID technology and current measurement technology. Not only for electrical equipment inventory checking, but also for working status real-time control and capacity utilization control. MR3872C has two male and female power input/output plug, easy to fixed on equipment. In real-time to control equipment current.
Product parameters
- Electrical Features
- AC Input Current 0A~10A
- AC Input Volt?110V ~ 130V/60Hz ?220V ~ 230V/50Hz
- Measuring Accuracy?0A~2A，deviation ±5mA?2A~10A，deviation±10mA
- Air Discharge 8000V
- Power Supply Mode?AC powered (build-in back battery)
- Battery 1200mAh
- Life Time?5 years
- RF Features
- Working Frequency 2.4GHz
- MAX Output Power 0dBm
- Modulation Mode GFSK
- Data Rate 1Mbps
- Dimension Body：56.02×36.58×27.84mm?Cable:235mm Female 405mm?Male
- Weight 170g
- Environment Features
- Working Temperature? -20℃ to +60℃
- Store Temperature -40℃ to +80
